The JONSEN B700B is a compact multiparameter monitoring platform developed for portable deployment. Its bright 7-inch LCD presents waveforms, numerical values, and alarm status in a clear layout. The standard monitoring screen can display ECG, SpO2 plethysmographic, and respiration waveforms. With a 5-lead ECG configuration, users can switch to the full-lead ECG screen to view leads I, II, III, aVR, aVL, aVF, and V simultaneously. Parameter areas provide convenient access to HR, NIBP, SpO2, PR, RR, and single-channel TEMP values.

The B700B uses the same internal structure, functional platform, and board configuration as the B700A, so its monitoring, data storage, alarm, and connectivity capabilities remain consistent. The standard parameter set includes 3-lead or 5-lead ECG, SpO2, NIBP, RESP, and single-channel TEMP monitoring, with HR, PR, and RR derived from the corresponding signals. The B700B stores up to 720 hours of trend data, 1,000 NIBP events, two hours of waveform review, and 200 alarm events. Stored data are retained in non-volatile memory. Audible, visual, and voice alarm indications support parameter review. A USB interface supports data export, while wired connectivity is standard and wireless connectivity is available as an option.

The B700B uses a plastic enclosure with silicone buttons and a rotary control. Its stainless-steel handle is mounted externally rather than integrated into the enclosure. The handle assists with carrying and allows the monitor to hang on a dimensionally and structurally compatible bed rail or support surface. A built-in rechargeable lithium battery supports mobile use, while a resistive touchscreen and a carrying and emergency bag are available as optional configurations. The platform can support veterinary monitoring projects and, where the intended use, patient category, accessories, and local registration have been confirmed, selected human patient-monitoring applications.

Key Features

·         Bright 7-inch LCD for waveforms, numerical values, and alarm status

·         Plastic enclosure with silicone buttons and a rotary control

·         3-lead or 5-lead ECG with standard and full-lead ECG display modes

·         ECG and HR, SpO2 and PR, NIBP, RESP and RR, and single-channel TEMP monitoring

·         Up to 720 hours of trend data, 1,000 NIBP events, two hours of waveform review, and 200 alarm events

·         Non-volatile storage for retained review data

·         Audible, visual, and voice alarm indications

·         USB data export, wired connectivity, and optional wireless connectivity

·         Externally mounted stainless-steel handle for carrying or hanging on compatible supports; optional resistive touchscreen and carrying bag

·         Available for OEM, ODM, and SKD projects, subject to confirmed project scope
