The JONSEN B700A is a compact multiparameter monitoring platform developed for portable deployment. Its bright 7-inch LCD presents waveforms, numerical values, and alarm status in a clear layout. The standard monitoring screen can display ECG, SpO2 plethysmographic, and respiration waveforms. With a 5-lead ECG configuration, users can switch to the full-lead ECG screen to view leads I, II, III, aVR, aVL, aVF, and V simultaneously. Parameter areas provide convenient access to HR, NIBP, SpO2, PR, RR, and single-channel TEMP values.

The standard parameter set includes 3-lead or 5-lead ECG, SpO2, NIBP, RESP, and single-channel TEMP monitoring, with HR, PR, and RR derived from the corresponding signals. The B700A stores up to 720 hours of trend data, 1,000 NIBP events, two hours of waveform review, and 200 alarm events. Stored data are retained in non-volatile memory. Audible, visual, and voice alarm indications help users identify parameter changes that require attention. A USB interface supports data export, while wired connectivity is standard and wireless connectivity is available as an option.

The integrated handle, compact enclosure, and built-in rechargeable lithium battery support movement between monitoring locations. An optional carrying and emergency bag is available for transport and field use. An optional rear clamp or mounting bracket can secure the monitor to a bedside location or another compatible support surface. A resistive touchscreen is also available as an optional configuration. The platform can support veterinary monitoring projects and, where the intended use, patient category, accessories, and local registration have been confirmed, selected human patient-monitoring applications.

Key Features

·         Bright 7-inch LCD for waveforms, numerical values, and alarm status

·         Compact enclosure with an integrated carrying handle

·         3-lead or 5-lead ECG with standard and full-lead ECG display modes

·         ECG and HR, SpO2 and PR, NIBP, RESP and RR, and single-channel TEMP monitoring

·         Up to 720 hours of trend data, 1,000 NIBP events, two hours of waveform review, and 200 alarm events

·         Non-volatile storage for retained review data

·         Audible, visual, and voice alarm indications

·         USB data export, wired connectivity, and optional wireless connectivity

·         Optional resistive touchscreen, carrying bag, and rear clamp or mounting bracket

·         Available for OEM, ODM, and SKD projects, subject to confirmed project scope
